China Phenolic Casters Manufacturer
When it comes to industrial mobility solutions, phenolic casters are a top choice for their exceptional strength, durability, and resistance to harsh environments. As a leading phenolic caster manufacturer in China, we specialize in producing high-quality phenolic wheels and casters engineered for heavy-duty performance across multiple industries.
What Is a Phenolic Caster?
A phenolic caster is a wheel made by combining phenolic resin with macerated fabric under high pressure and heat. The result is a wheel with high impact resistance, exceptional load capacity, and outstanding temperature tolerance. These casters are ideal for industrial environments where floors must be protected while carrying heavy loads.
Key Features of Our Phenolic Casters
Feature |
Description |
|
Load Capacity |
Supports up to 200–1000 lbs per wheel |
| Temperature Resistance |
Operates in -40~+572℉ (even higher with special resin) |
|
Floor Protection |
Non-marking material, safe for concrete and epoxy floors |
| Moisture & Chemical Resistance |
Excellent resistance to oil, grease, and mild chemicals |
|
Noise Reduction |
Quieter than steel wheels in most applications |
| Brake Options |
Available with side brake, total lock, or directional lock |
Applications of Phenolic Casters
Our phenolic caster wheels are widely used in various demanding environments, such as:
Warehouse & Distribution Carts
Tooling Racks and Fixtures
Food Processing Equipment
Manufacturing Lines
Heavy-duty Dollies and Trolleys
Bakeries and Ovens (due to heat resistance)
These casters are perfect for operations where high load-bearing and temperature endurance are critical.
Why Choose Us – Trusted Phenolic Caster Manufacturer in China
As an experienced phenolic caster factory in China, we offer:
✅ OEM & ODM services with custom branding
✅ Strict quality control at every stage of production
✅ Competitive factory prices
✅ Fast lead times & reliable global shipping
✅ Support from engineering to after-sales service
Our brand, TARGET Casters, is trusted by customers worldwide for performance, reliability, and value. We don’t just make casters — we help businesses move smarter and work safer.
Product Specifications – Hot Selling Models
Phenolic Casters Wheels Provided by TARGET Casters |
||||||
Temperature Range(℃) |
TARGET Number |
Material |
Wheel Diameter |
Wheel Tread Width |
Load Capacity |
Caster Type / Fastening Type |
| -20℃ to 180℃（-4~+356℉） | TC-PHPRA100-01 TC-PHPSA100-01 TC-PHPSE100-01 |
Phenolic + Stainless Steel | 4″ φ100mm |
1.25″ 32mm |
130kg（290 lbs） | Plate Rigid、Plate Swivel、Plate Swivel Brake |
| 33W PH10001 | Phenolic | 4″ φ100mm |
2″ 50mm |
350kg（770 lbs） | High Temperature Wheel | |
| 33W PH12501 | Phenolic | 5″ φ125mm |
2″ 50mm |
400kg（880 lbs） | High Temperature Wheel | |
| 33W PH15001 | Phenolic | 6″ φ148mm |
2″ 50mm |
450kg（990lbs High-Temp 660lbs） | High Temperature Wheel | |
| -40℃ to 220℃（-40~+428℉） | TC-PGPSA075-01 TC-PGPRA075-01 TC-PGPSB075-01 |
Phenolic + Glass Fiber | 3″ φ75mm |
1.8″ 46mm |
181kg（400 lbs） | Plate Swivel、Plate Rigid、Plate Swivel Brake |
| TC-PGPSA100-01 TC-PGPRA100-01 |
Phenolic + Glass Fiber | 4″ φ101mm |
1.42″ 36mm |
100kg（220 lbs） | Plate Swivel、Plate Rigid | |
| TC-PGPSB100-01 | Phenolic + Glass Fiber | 4″ φ101mm |
2″ 49.5mm |
260kg（573 lbs） | Plate Swivel Brake | |
| TC-PGPRA125-01 TC-PGPSB125-01 |
Phenolic + Glass Fiber | 5″ φ127mm |
1.89″ 48mm |
320kg（705 lbs） | Plate Rigid、Plate Swivel Brake |
|
| TC-PGPSB150-01 TC-PGPRA150-01 |
Phenolic + Glass Fiber | 6″ φ152mm |
1.89″ 48mm |
380kg（840 lbs） | Plate Swivel Brake、Plate Rigid | |
| TC-PGPSB200-01 TC-PGPRA200-01 |
Phenolic + Glass Fiber | 8″ φ203mm |
1.89″ 48mm |
400kg（880 lbs） | Plate Swivel Brake、Plate Rigid | |
| -40℃ to 300℃（-40~+572℉） | TC-PBPSA075-01 | Phenolic + Glass Fiber | 3″ φ75 |
1 1/2″ 38mm |
115kg（254 lbs） | Plate Swivel |
| TC-PBPSE100-01 | Phenolic + Glass Fiber | 4″ φ100mm |
1.25″ 32mm |
140 kg （300 lbs） |
Plate Swivel Brake | |
| TC-PBPSA125-01 | Phenolic + Glass Fiber | 5″ φ125mm |
1.25″ 32mm |
150 kg (330 lbs) | Plate Swivel | |
| TC-PBPRA150-01 | Phenolic + Glass Fiber | 6″ φ150mm |
2″ 50mm |
380kg（840 lbs） | Plate Rigid | |
Custom sizes and mounting options are also available upon request.
Partner With Us
Looking for a reliable phenolic caster supplier from China? Whether you need bulk quantities, special specifications, or branded packaging, TARGET Casters is ready to be your trusted partner in global mobility solutions.
Contact us today to get samples, catalogs, or a custom quote.
